8-Inch Dental Patient Monitor | ECG, NIBP, SpO2, TEMP & RESP — Multi-Parameter Vital Signs Monitor

Professional 8-Inch Multi-Parameter Patient Monitor for Dental & Clinical Use

Ensure complete patient safety during every procedure with real-time monitoring of all critical vital signs. Designed for dental practices, oral surgery centers, and clinical environments — this monitor delivers hospital-grade accuracy in a compact, reliable unit.

🔑 Key Benefits

• Real-Time Vital Sign Monitoring — Continuously tracks ECG, blood pressure, SpO2, temperature, and respiration for full patient safety during surgery
• Ideal for Implant & Oral Surgery — Provides the reliable data foundation needed for successful outcomes in high-risk procedures
• Suitable for All Patient Types — Adults, children, and newborns; perfect for general dentistry, pediatric dentistry, and oral surgery centers
• Built-In Lithium Battery — Continues monitoring even during power failure; AC and DC compatible
• 384-Hour Trend Memory — Stores all parameter data and dynamic waveforms for comprehensive patient records

✅ Features at a Glance

• 8-inch high-brightness, high-resolution color LCD display — comfortable, glare-free viewing
• 7-channel ECG waveform display with 5-minute playback and automatic ST segment detection
• Customizable alarm limits with automatic sound and light alerts
• Anti-movement, anti-defibrillation, and anti-electrosurgical interference protection
• Drug solubility calculation and arrhythmia analysis functions
• Remote central monitoring network interface
• Standard parameters: ECG · NIBP · SpO2 · TEMP · RESP

📦 Package Includes

1. 1 × Dental Patient Monitor
2. 1 × Adult Blood Pressure Cuff
3. 1 × SpO2 Probe
4. 1 × 5-Lead ECG Cable
5. 1 × Temperature Probe
6. 1 × User Manual

⚙️ Technical Specifications

ECG
Leads: I, II, III, aVF, aVR, aVL, V1–V6 | HR Range: 15–300 bpm (Adult), 15–350 bpm (Pediatric) | Accuracy: ±1 bpm | ST Detection: -2.0 mV to +2.0 mV | Scan Rate: 12.5 / 25 / 50 mm/s

NIBP (Blood Pressure)
Method: Oscillometric | Modes: Manual / Auto / Continuous | Adult Systolic: 40–270 mmHg | Accuracy: Max avg error ±5 mmHg | Overvoltage Protection: Dual safety

SpO2
Range: 70–100% (±2%) | Pulse Rate: 20–300 bpm | Resolution: 1%

Temperature
Range: 0°C–45°C | Accuracy: ±1°C | Resolution: 0.1°C | Response Time: 1s

Respiration
Adult: 7–120 brpm | Pediatric: 7–150 brpm | Accuracy: ±2 brpm

Power
AC: 220V, 50Hz | Max Power: 70VA | Operating Temp: 5–40°C | Humidity: ≤85% RH

🏥 Suitable For

Dental clinics · Oral surgery centers · Pediatric dentistry · ICU · CCU · Emergency centers · Operating rooms · Obstetrics & Gynecology · Internal medicine departments
